TOYOTA RAV4 XA50 XA50 HEV (2018+) SERVICE WORKSHOP MANUAL IN PDF format (42322 pages) + Toyota GSIC online manual supplied as a downloadable link.
This comprehensive service workshop manual is tailored for the Toyota RAV4 XA50 and XA50 HEV, covering models from 2018 and onwards. Packed with detailed information, it's a vital resource for anyone looking to maintain or repair their RAV4.
ENGINE FEATURED IN THIS MANUAL: 2.0 L M20A-FKS I4 & 2.5L A25A-FXS I4
REFERENCE POWERTRAIN Engine: Petrol : 2.0 L M20A-FKS I4 2.5 L A25A-FKS I4 Petrol Hybrid: 2.5 L A25A-FXS I4 Petrol Plug-in Hybrid (PHEV):2.5 L A25A-FXS I4 Electric Motor: Permanent magnet synchronous motors with various configurations. Power Output: 126 kW (169 hp) for 2.0 L engines 151 kW (202 hp) for 2.5 L engines 163 kW (219 hp) for hybrid (combined) 225 kW (302 hp) for PHEV (combined)
Transmission: 6-speed manual 8-speed AWF8F35/UA80E "Direct Shift" automatic K120 CVT with physical first gear Aisin Seiki T110 eCVT with sequential shift mode (hybrid)
Hybrid Drivetrain: Power-split for hybrid models PHEV system for plug-in hybrids
Plug-in Charging Features: 6.6 kW AC for Prime models V2L: 1.5 kW capability for Prime models
