LEXUS NX200 / NX200t (2014-2021) SERVICE WORKSHOP MANUAL

LEXUS NX200 / NX200t (2014-2021) SERVICE WORKSHOP MANUAL EXTRACTION FROM TOYOTA GSIC FOR VIEWING VIA WEB BROWSER (INTERNET EXPLORER ONLY) SUPPLIED AS DOWNLOADABLE LINK.

ENGINE FEATURED IN THIS MANUAL: 2.0L 8AR-FTS (ONLY)

REFERENCE POWERTRAIN:
Engine
1986 cc 3ZR-FAE I4 (NX 200; ZGZ10)
1998 cc 8AR-FTS turbo I4 (NX 200t/300; AGZ10/15)
2494 cc 2AR-FXE I4 (NX 300h; AYZ10/15)

Electric motor
105 kW (141 hp; 143 PS) 2JMsynchronous (NX 300h, front)
50 kW (67 hp; 68 PS) 2FMsynchronous (NX 300h, rear)
110 kW (148 hp; 150 PS) (NX 200)
175 kW (235 hp; 238 PS) (NX 200t/300)
112 kW (150 hp; 152 PS) (NX 300h, gasoline engine only);
145 kW (194 hp; 197 PS) (NX 300h, combined system output)

Transmission
6-speed U661 E/F automatic (NX 200t/300)
CVT (NX 200)
eCVT (NX 300h)
