BMW X1 E84 (2009-2015) FACTORY SERVICE WORKSHOP MANUAL IN PDF FORMAT (4096 PAGES) SUPPLIED AS DOWNLOADABLE LINK.
In-depth maintenance, service and repair information for BMW X1 models 2009-2015. The aim throughout has been simplicity and clarity, with practical explanations, step-by-step procedures and accurate specifications. Whether you're a professional or a do-it-yourself BMW owner, this manual helps you understand, care for and repair your BMW X1. Note that this manual is designed for specific and most common repair procedures hence it is not based on a complete disassembly of the machine.
ENGINE COVERED IN THIS MANUAL: N47D20 (DIESEL) ONLY
WHAT'S INSIDE ? - Maintenance procedures from changing the ATF to replacing the fresh air microfilter. - Step-by-step variable camshaft timing (VANOS) service - Cylinder head cover gasket and crankshaft seal replacement. - Cooling system and radiator service. - Fuel injection and ignition system diagrams and explanations - Information about advanced technical features such as Valvetronic, xDrive and DSC (dynamic stability control). - Suspension repair procedures. - Brakes, steering and ABS troubleshooting and repair. - Heating and air-conditioning repair, including A/C component replacement. - Body, hood and sunroof repairs and adjustments. - Electrical system service, with an easy-to-use illustrated component locator section. - Comprehensive wiring schematics, including power distribution and grounds. - BMW OBD II diagnostic trouble codes, SAE-defined OBD II P-codes, as well as basic scan tool operation. - BMW factory tolerance, wear limits, adjustments and tightening torques.
